113674_0711 5-9
Kohler CV730 & CV740 Engine
NOTES:
1. Supplied with the engine.
2. Part of the mower’s main wire harness.
3. Contains a 40 amp fuse.
4. Torque to 30 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 N/A 1 ENGINE, KOHLER CV730
N/A 1 ENGINE, KOHLER CV740
2 788943 1 AIR FILTER INDICATOR
3 601216 1 ELBOW STREET FITTING
4 796672 1 OIL DRAIN VALVE, 3/8-18
5 787713 3” HOSE, 0.50" LOW PRESSURE
6 058776 1 NT .312-18 HXZY NL
7 768523 4 FW .343 X .687 X .051/.080H
8 602776 1 MUFFLER
9 029751 2 CS .375-16 X 1.000 HXFLK
10 705137 4 FW .391 X 1.250 X .060 ZNY
11 786632 1 RED POSITIVE BATTERY CABLE
12 744284 1 NEGATIVE BATTERY CABLE
13 029876 1 LW .312 INT-EXT TOOTH Z
14 789131 1 FAN CAP
15 000331 4 WIRE TIE, SMALL/SHORT
16 603112 2 CLAMP, 3/16"
17 603326 36” FUEL LINE, 3/16"
18 000323 2 HOSE CLAMP
19 015818 29” FUEL LINE, 1/4"
20 034280 1 CS .312-18 X .750 HX G5
21 043570 1 CLAMP
22 034272 1 NT .312-18 HX G5 ZNYC
23 016899 2 NT .375-16 HXFLK ZNYC
24 050161 1 CS .312-18 X 1.750 HX G5
25 792788 3 SC.375-16 X 1.0HX FL STP
FUEL & VAPOR LINE LENGTHS
29" VALVE TO ENGINE (FUEL)
36" TEE TO ENGINE (VAPOR)
A
B
