Maximum Vertical
Refresh Rate 85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and
configuration. See table below.
Multi-display Support Integrated dual independent monitor support facilitated via one VGA port and one
DisplayPort integrated on the back plane of the system board and presented as
part of the rear I/O set of interfaces. DVI supported via optional HP DisplayPort to
DVI-D adapter.
Graphics/Video API
Support Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver update)
Resolutions Supported
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.
Maximum Refresh Rate (Hz)
Resolution Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60 *
* Only supported when using a DisplayPort connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections.
NVIDIA Quadro NVS
290 256MB PCIe Dual
Head Form Factor Low Profile
Bus Type PCIe x16
Memory 256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and
Texture storage
Connector DMS-59; includes one DMS-59 to Dual VGA cable. A DMS-59 to Dual
DVI-I cable is available as an option.
Display resolution
support Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays
at 1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft Windows
RAMDAC Integrated dual 400MHz
Color planes 32-bit color buffer
Overlay planes Hardware supported
nView architecture Advanced multi-display desktop & application management seamlessly
integrated into Microsoft Windows.
Multi-Monitor support Dual monitor support
DVI support DMS-59 (to dual DVI-SL)
High-definition Video
Processor (HDVP) Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
QuickSpecs
HP Compaq 8100 Elite PC
Technical Specifications - Graphics
DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010 Page 27
