OPERATION
POWER TRIM/TILT SWITCH
POWER TRIM/TILT SWITCH
(single type)
(dual type)
(RIGHT) (LEFT)
POWER TRIM/TILT SWITCH
POWER TRIM/TILT SWITCH
BOW TOO LOW DUE TO
1. LOAD IN THE FRONT
2. MOTOR TRIMMED TOO LOW
BOW TOO HIGH DUE TO
1. LOAD IN THE REAR
2. MOTOR TRIMMED TOO HIGH
MOTOR
TRIMMED TOO
LOW MOTOR
TRIMMED TOO
HIGH
MOTOR TRIMMED
CORRECTLY
ROUGH
WAVES
Top-Mount Type Side-Mount Type
Panel-Mount Type
