27
Engine Cover Lock Levers Transom Angle Adjusting Rod
CONTROLS AND FEATURES
TRANSOM ANGLE
ADJUSTING ROD
FREE
SIDE
ENGINE COVER
LOCK LEVER
LOCK
FREE
LOCK
FRONT
ENGINE COVER
LOCK LEVER
NUT
NUT The engine cover lock levers fasten
the engine cover to the outboard
motor.
The transom angle adjusting rod
limits the tilt angle of the outboard
motor when fully lowered.
Proper adjustment prevents the
outboard motor from being trimmed
too low (p.
). 51
