10 hp photosmart 720 user’s manual
Camera Parts
# Name Description
1 Memory card door Allows access to insert or remove the
memory card. Also allows access to
the connectors for USB, TV, and
power adapter.
2 Memory card slot Allows memory card to be inserted
3 USB connector Provides connection to either a
computer or printer
4 TV connector Provides audio/video output to a TV
5 Power adapter
connector
Provides connection for an optional
HP AC adapter
6 Display button Turns on Preview mode or turns off
the Image Display
7 Arrow buttons Moves to menu options and
navigates through images
12
13 14
1
2
3
4
5
6
7
8
9
10
11
