Getting to know the wireless gateway, Wireless gateway rear panel, Wireless gateway ports – HP hn200w User Manual
Page 7: All gateway connections are made on the rear panel
7
getting to know the wireless
gateway
wireless gateway rear panel
All Gateway connections are made on the rear panel.
wireless gateway ports
Wireless Gateway Rear Panel
WAN
You will connect the DSL or cable modem
to the Wide Area Network (WAN) port.
LAN Ports 1–4
You can connect devices on your LAN,
such as PCs and print servers, to the four
LAN ports.
POWER
RESET
LAN
UPLINK
WAN
2
3
4
1
