Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
5.3 Preparing the Expansion Base
for Disassembly
Perform the following steps before disassembling the
expansion base:
1. If the computer is in the expansion base, turn off the
computer and disconnect the expansion cable from
the computer.
2. Remove the computer from the expansion base.
3. Disconnect the AC adapter and all external devices from
the expansion base.
Disassembly Sequence Chart
Section Description # of Screws Removed
5.3 Preparing the Expansion Base
for Disassembly
5.4 Installing an Optional Hard Drive
Hard drive carrier
Hard drive rear panel
Hard drive 1
2
4
