Heat & Glo • XLR-N-CE, XLR-PB-CE • 2198-900 Rev. L • 3/13 64
Service Parts XLR-N-CE, XLR-PB-CE
Beginning Manufacturing Date: Mar 2010
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please
provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
ITEM DESCRIPTION COMMENTS PART NUMBER
Battery Pack 2166-323
Elbow Heat Shield 2143-168
Exhaust Restrictor 530-299
Gasket Assembly
2113-080 Contains burner neck, shutter bracket, vent, seal cap, valve plate,
and air passage gaskets
Glass Latch Assembly Pkg of 2 33858/2
Heat Shield, Inner 2198-130
Jumper Wire, Wall Switch 2179-300
Nailing Tabs 2198-132
Rocker Switch 2206-299
Switch Assembly, Reset 2264-060
Touch Up Paint TUP-GBK-12
Wall Switch Kit WSK-21-W
Wire, Jumper 2187-198
Wire Assembly, Module Reset 2201-030
Conversion Kit N PB2N-XLR-CE
Conversion Kit B P2B-XLR-CE
Conversion Kit P N2PB-XLR-CE
Pilot Orifi ce N 593-528
Pilot Orifi ce B 593-529
Pilot Orifi ce P 593-527
Regulator N NGK-DXF-NP
Regulator P & B LPK-DXF-NP
