3 Connecting to a Windows NT Server 3.51
Windows NT Workstation Version 4.0
Windows NT
Workstation
Version 4.0
Requirements
• HP Vectra with Microsoft Windows NT Workstation 4.0 installed.
• IBM AUTO LANStreamer PCI Drivers diskettes Ver. 3.04
• Driver Name: OEMSETUP.inf Size: 67KB Date: 10/18/96
• Microsoft Windows NT Workstation 4.0 and Service Pack Media.
• Microsoft Windows NT Server 3.51machine that supports Net BEUI, TCP/
IP, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
Device Configuration
• I/O Base Address FC00h
• Interrupt Request Level 9
Procedure
1 With the HP Vectra turned off install the IBM LANStreamer 16/4 PCI TR
adapter card into a PCI slot.
2 Insert the IBM LANStreamer TR drivers disk 1 of 6 (AUTO LANStreamer
PCI Diagnostic Disk) and power on the machine.
3 After the machine boots, verify that the adapter finished testing and that
the adapter is “OK.”
4 Click on “F3” to exit, and then press “CTRL+ALT+DEL.”
5 After windows loads, log into NT workstation with administrator
privileges. (If you do not have the required information, contact your
network administrator)
6 Click on “Start”, up to “Settings”, and open “Control Panel.”
7 Select the “Network” icon in the “Control Panel” program group.
8 Click on “YES” in the “Network Settings“ dialog box, and NT Networking
will be installed on your computer.
9 With “Wired to the Network” checked, click on “Next.”
10 Click on “Select from List”, then click “Have Disk.”
11 Set the path to “A:\NT” in the “Insert Disk” dialog box, and then insert the
disk 4 of 6 , Auto LANStreamer PCI drivers disk. (If you have an HP
preloaded HDD, set path to “C:\LANDRV\LNSTRM\DISK4\NT\”)
