7
HERMETIC COMPRESSORS
Performance Data - Low Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, S for Beacon II™
R-404A/507
Model
Compressor
Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
CH*011L6 CF04K6E 7,030 6,240 5,370 3,850 3,330 2,630
CH*014L6 CF06K6E 10,500 9,380 7,830 6,090 4,890 4,080
CH*019L6 CF06K6E 12,100 10,180 8,910 6,580 5,530 4,570
CH*025L6 CF09K6E 15,550 14,500 12,700 9,000 7,560 6,230
CH*031L6 CF12K6E 18,840 17,800 15,140 11,540 9,790 8,070
R-404A/507
Model
Compressor
Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
CH*011L6 CF04K6E 6,840 5,750 4,920 3,650 3,020 2,360
CH*014L6 CF06K6E 9,900 8,840 7,750 5,670 4,710 3,680
CH*019L6 CF06K6E 11,400 10,100 8,750 6,040 5,030 4,150
CH*025L6 CF09K6E 15,400 13,700 12,000 8,300 6,950 5,750
CH*031L6 CF12K6E 17,690 16,800 14,360 10,910 9,170 7,470
R-404A/507
Model
Compressor
Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
CH*011L6 CF04K6E 6,310 5,170 4,460 3,300 2,660 2,070
CH*014L6 CF06K6E 9,310 8,280 7,280 5,280 4,350 3,510
CH*019L6 CF06K6E 10,700 9,430 8,170 5,810 4,570 3,700
CH*025L6 CF09K6E 14,500 12,800 11,200 8,130 6,410 5,220
CH*031L6 CF12K6E 17,600 15,090 13,410 10,700 9,040 7,320
R-404A/507
Model
Compressor
Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
CH*011L6 CF04K6E 5,240 4,450 3,620 2,630 2,100 –
CH*014L6 CF06K6E 8,310 7,340 6,420 4,580 3,730 2,990
CH*019L6 CF06K6E 9,330 8,170 7,040 4,920 3,980 3,090
CH*025L6 CF09K6E 12,700 11,400 9,900 7,030 5,760 4,590
CH*031L6 CF12K6E 15,700 14,000 12,400 9,250 7,690 6,100
