SEMI-HERMETIC COMPRESSORS
Unit Specifications
* = T for Outdoor, N for Indoor, S for Beacon II™
++ = See Dimensional Drawings for details.
†
= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at
different distances, deduct the following from the unit values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA
for 80 feet, deduct 18 dBA. This data is typical of “free field” conditions for horizontal air cooled condensing units
at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing unit
installation. Factors such as reflecting walls, background noise and mounting conditions may have a significant
influence on this data.
Model
Fig. ++
Compressor
Connections (ID) Receiver
90% Full
Lbs.
Fan(s)
Dimensions
Net Wt.
Lbs.
Sound
Data dBA
†
Liquid Suction
D (In.)
W (In.)
H (In.)
CS*005H2
A
HAG-0050
3/8
1/2
6.0
1
28-1/4
23-3/4
17-1/4
161
66
CS*008H2
A
KAN-0075
3/8
5/8
6.0
1
28-1/4
23-3/4
17-1/4
180
66
CS*008M2
A
KAE-0075
3/8
5/8
6.0
1
28-1/4
23-3/4
17-1/4
180
66
CS*010H2
A
KAR-0100
3/8
5/8
6.0
1
28-1/4
23-3/4
17-1/4
175
66
CS*010M2
A
KAM-0100
3/8
5/8
6.0
1
28-1/4
23-3/4
17-1/4
178
66
CS*015H2
B
KAG-0150
3/8
7/8
10.0
2
28-1/4
37-3/4
17-1/4
221
69
CS*020H2
B
ERA-0200
3/8
7/8
10.0
2
28-1/4
37-3/4
17-1/4
293
69
CS*020M2
B
KAK-0200
3/8
7/8
10.0
2
28-1/4
37-3/4
17-1/4
189
69
CS*021M2
B
ERC-0200
3/8
7/8
10.0
2
28-1/4
37-3/4
17-1/4
301
69
CS*029M2
C
ERF-0310
1/2
7/8
16.0
2
28-1/4
37-3/4
19-3/4
391
69
CS*030H2
D
ERF-0310
1/2
7/8
22.0
1
30-1/4
42-1/2
29-3/4
385
70
CS*040H2
D
NRB-0400
1/2
1-1/8
22.0
1
30-1/4
42-1/2
29-3/4
460
71
CS*050H2
D
NRA-0500
1/2
1-1/8
22.0
1
30-1/4
42-1/2
29-3/4
462
71
CS*050M2
D
NRM-0500
1/2
1-1/8
22.0
1
30-1/4
42-1/2
29-3/4
462
71
CS*005M6
A
HAJ-005E
3/8
1/2
5.5
1
28-1/4
23-3/4
17-1/4
161
66
CS*010M6
A
KAR-010E
3/8
5/8
5.5
1
28-1/4
23-3/4
17-1/4
178
67
CS*020M6
B
KAK-020E
3/8
7/8
9.0
2
28-1/4
37-3/4
17-1/4
189
69
CS*021M6
B
ERC-021E
3/8
7/8
9.0
2
28-1/4
37-3/4
17-1/4
301
70
CS*030M6
D
ERF-031E
1/2
7/8
20.0
1
30-1/4
42-1/2
29-3/4
397
71
CS*040M6
D
NRB-040E
1/2
1-1/8
20.0
1
30-1/4
42-1/2
29-3/4
460
73
CS*005L6
A
KAN-005E
3/8
1/2
5.5
1
28-1/4
23-3/4
17-1/4
172
67
CS*008L6
A
KAM-007E
3/8
5/8
5.5
1
28-1/4
23-3/4
17-1/4
172
67
CS*010L6
A
KAJ-010E
3/8
5/8
5.5
1
28-1/4
23-3/4
17-1/4
178
67
CS*015L6
B
KAL-015E
3/8
7/8
9.0
2
28-1/4
37-3/4
17-1/4
225
69
CS*020L6
B
EAD-020E
3/8
7/8
9.0
2
28-1/4
37-3/4
17-1/4
291
70
CS*021L6
B
EAV-021E
3/8
7/8
9.0
2
28-1/4
37-3/4
17-1/4
301
70
CS*030L6
C
LAH-032E
1/2
7/8
14.0
2
28-1/4
37-3/4
19-3/4
357
71
CS*030E6
C
LAC-032E
1/2
7/8
14.0
2
28-1/4
37-3/4
19-3/4
391
71
CS*040L6
D
NRD-032/040E
1/2
1-1/8
20.0
1
30-1/4
42-1/2
29-3/4
457
73
