7
If belt is not broken, pull it off the motor
pulley (B).
4-4 4-5 4-6
4-7 4 - 8
4 - 9
Lift up end of agitator. Remove old belt
f rom agitator pulley (C) and replace with
new belt. Lettering on belt must be visible. S t retch belt back and attach to motor pulley.
Hold opposite end of agitator in place.
Push belt end forw a rd, rotating end plate
(D) until it slides into place. Tu rn agitator,
making sure it rotates fre e l y.
Position nozzle cover on front lip of
nozzle base. Press cover into place.
Tu rn nozzle over and replace scre w s .
The agitator brush ro l l
re p l a c e m e n t
What to buy
The agitator may be replaced with either a
single or double row of bru s h e s .
Single row of brushes - Hoover part N o .
4 8 4 1 4 - 0 5 1 .
Double row of brushes - Hoover part N o .
4 8 4 1 4 - 0 4 9 .
When to re p l a c e
Disconnect hose power cord from elec-
trical outlet.
To check condition of brushes, move edge
of card across agitator opening while turn-
ing agitator. To maintain cleaning eff e c t i v e-
ness, replace brushes if they do not touch
c a rd .
How to re p l a c e
Disconnect hose power cord from elec-
trical outlet and disconnect power noz-
zle from extension wands.
1. Remove nozzle cover, agitator and belt
as shown in Figs. 4-2 to 4-5.
2. Lift out old agitator and discard .
3. Replace new agitator and belt as
shown in Figs 4-4 to 4-7.
The headlight
( PowerMAX™ power nozzle only )
The headlight,located under the nozzle
c o v e r.
Use only Hoover part
N o .2 7 3 1 7 - 3 0 7 ,
which is a fused bulb, when replacing the
h e a d l i g h t .
How to to re p l a c e
Disconnect hose power cord from elec-
trical outlet and disconnect power noz-
zle from extension wands.
1. Remove the nozzle cover as shown in
Figs. 4-2 to 4-5.
2. Push old bulb into socket and twist to
remove. Push new bulb into socket and
twist into place.
3. Replace nozzle cover.
B
D
C
