Quickspecs – HP COMPAQ 8100 User Manual

Page 12

HP DisplayPort to DVI-D Adapter

HP DisplayPort to VGA Adapter
HP DisplayPort to HDMI Adapter

HP DisplayPort Cable

* When ordered with an Nvidia Quadro NVS 295 card, the PC is shipped with two DisplayPort to VGA Adapters. When an
Nvidia Quadro NVS 295 card is purchased as an after-market option, it comes with two DisplayPort to DVI-D Adapters.

Audio/Visual

High Definition Audio with Realtek ALC261 codec (all ports are stereo)

Microphone/Headphone* and dedicated headphone front ports

Line-out and Line-In rear Ports*

Multi-streaming capable*

Internal Speaker (standard)

HP Thin USB Powered Speakers

HP TV Tuner

* The front microphone port is re-taskable as a Line-in, Microphone-in or Headphone-in port. Rear audio input ports are re-
taskable as a Line-in or Microphone-in port. External speakers must be powered externally. Multi-streaming can be enabled in
the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks. This allows for
different audio applications to use separate audio ports on the system. For example, the front jacks could be used with a
headset for a communications application while the rear jacks are being used with external speakers and a multimedia
application.

Note: The audio ports/jacks provided by all of our systems are 3.5mm in diameter. This would include both the front jacks and
rear jacks, for audio in/out, mic in and headphone out.

Input/Output Devices

PS/2 Standard Keyboard

USB Standard Keyboard

USB CCID SmartCard Keyboard

USB Mini Keyboard
USB and PS/2 Washable Keyboard

PS/2 Optical Scroll Mouse
USB Optical Scroll Mouse

USB Laser Scroll Mouse

USB and PS/2 Washable Mouse

Miscellaneous Devices and Configurations

FireWire (IEEE 1394) Card
Serial Port Adapter (RS-232 compatible)

Parallel Port Adapter
eSATA Port Adapter

QuickSpecs

HP Compaq 8100 Elite Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13524 Worldwide — Version 26 — September 30, 2011

Page 12
