Board components and features 4
1 Board components and features
Figure 1-1 6-Port SATA RAID Controller
1 Internal SATA port 0 3 Flash jumper
2 Internal SATA port 5 4 I2C connector
Controller specifications and attributes
Table 1-1 Controller specifications and attributes
Ambient temperature 0°C to 50°C (forced airflow is recommended, but not required)
Relative humidity 10% to 90%, noncondensing
Altitude Up to 3,000 meters
Ripple and noise 50 mV peak-to-peak (max)
DC voltage 5 V ± 0.5 V
Maximum current 2.1 A at 5 V DC
Form factor Full-height, half length
PCI interface 64-bit, 66-MHz; compatible with 32-bit, 33-MHz slots
PCI compatibility PCI only
On-board cache 64 MB
Number of drives allowed per port 1
Maximum size of logical drive 2 TB
RAID levels supported 0, 1, 5, 10, 50
For a complete list of the controller attributes, see the HP website ( http://www.hp.com ).
