Harbor Freight Tools HEAVY-DUTY 1/2" VSR DRILL 3273 - Manual (Page 14)

Page 14 For technical questions, please call 1-800-444-3353. ITEM 3273
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description
1 Chuck
2 Retaining Ring Ø 32
3 Iron Bushing
4 Wool Washer
5 Spindle
6 Key 3 x Ø10
7 Bearing 6002
8 Screw ST4.2 x 3.5
9 Washer Ø4
10 Fender Ring Ø15
11 Gear Housing
12 Needle Bearing HK071109
13 Gear 3
14 Key 3 x Ø10
15 Gear 2
16 Needle Bearing HK071109
17 Middle Housing
18 Gear 4
19 Spring Ø12
20 Needle Bearing HK081210
21 Bearing 608
22 Fan
23 Rotor
Part Description
24 Bearing 607
25 Inner Bearing Cover
26 Ring Fender
27 Screw ST4.2 x 50
28 Washer Ø4
29 Stator
30 Rear Housing
31 Brush Holder Cap
32 Carbon Brush
33 Brush Holder
34 Direction Switch
35 Handle
36 Trigger
37 Screw ST2.9 x 12
38 Screw ST4.2 x 14
39 Cord Clamp
40 Cord
41 Handle
42 Screw ST4.2 x 14
43 Cord Protector
44 Chuck Screw
45 Auxiliary Handle (Not Shown)
