Model HCS-2,HCW-3/HCW-5/HCW-8
3-9. PARTS LIST (Continued)
Item Part
Qty.
No.
Number
Description
HCS-2
HCW-5
HCW-8
67
22560
Pan Support - Bottom
-
1
-
67
54263
Pan Support - Bottom - HCW-8
-
-
1
67
72188
Pan Support - Bottom - HCS-2
1
-
-
68
41556
Viewing Panel Bracket Assembly (R.H.)
1
2
2
69
NS03-017
Nut - #8 U-Type Clip - SN: IR022JB and below
-
AR
AR
√√√√√ 70
22604
Switch Assembly - Power
1
1
1
71
SC01-023
Screw #6-32 x 1/4" PH Rhd,
2
2
2
72
22589
Plate - Access
2
2
4
√√√√√ 73
16624
Light Indicator
-
2
2
√√√√√ 73
54085
Light Indicator - CE - Green
2
2
2
74
16731
Knob - Thermostat
1
1
1
√√√√√ 75
14250
Thermometer
1
1
1
76
22509
Plate - Access
1
1
1
77
22526
Pan - Bottom
-
1
-
77
38707
Pan - Bottom - HCW-8
-
-
1
77
72191
Pan - Bottom - HCS-2
1
-
-
√√√√√ 78
22601
High Limit
1
1
1
79
22514
Bracket - High Limit Clamp
1
1
1
√√√√√ 80
22673
Switch - 3 Position
1
1
1
81
15302
Guard - Switch
1
1
1
82
22815
Decal - Water Control Switch
1
1
1
83
22814
Decal - Bottom Control Panel
1
1
1
84
22667
Guard - Splash
1
1
1
85
LW02-004
Lockwasher (1/4" ext.)
AR
AR
AR
86
SC01-068
Screw #1/4-20 x 3/4"
8
8
8
87
SC01-002
Screw #10-32 x 1/2" PH Truss Hd.
2
2
2
88
22588
Mounting Block - Thermometer
1
1
1
89
66670
Plate - Electric Component
1
1
1
90
22607
Terminal Block Assembly
-
1
1
90
80573
Terminal Block Assembly - 220-240/3ph - HCW-5
-
1
-
90
53738
Terminal Block Assembly - Australian HCW-2
-
-
-
90
73525
Terminal Block Assembly - Australian HCS-2
1
-
-
91
NS02-001
Nut #10-32 Hex Keps
AR
AR
AR
√√√√√ 92
19405
Contactor
1
1
1
93
FP01-013
Bulkhead Adaptor
1
1
1
94
FP01-012
Nipple - Reducing
2
2
2
√√√√√ 95
14965
Kit - Valve - Solenoid (120 volt) 1
1 1
√√√√√ 95
14966
Kit - Valve - Solenoid - 240V-60Hz & 220V-50Hz 1 1 1
√√√√√ 95
32646
Valve - Solenoid - WRAS - UK
1
1
1
√√
96
FP01-014
Elbow (1/8" Brass)
1
1
1
√√√√√ 97
25208
Strainer - Water
1
1
1
98
FP05-005
Elbow (1/4 NPT to 1/4 NPT)
1
1
1
√√√√√ 99
64103
Thermostat Control
1
1
1
100
22886
End Channel (3-1/2" Bottom) - SN: IR023JB and Above
1
1
1
100
14402
Kit - HCW End Channel - SN: IR022JB and below
-
1
1
101
22813
Decal - Top Control Panel
-
1
1
101
61524
Decal - Top Control Panel - Pollo Loco
-
1
1
102
SC01-113
Screw - #6-32 x 1/2" PH Phd.
-
4
4
103
22508
Angle - Channel Mount (Upper)
-
2
2
104
22892
End Channel Assy (3-1/2" Top) SN: IR023JB and Above
-
1
1
104
14413
Kit - HCW End Channel - SN: IR022JB and below
-
1
1
√√√√√
recommended parts
109
3-6
