hp scanjet 4600 series digital flatbed scanners
appendix a
29
transparent materials adapter (TMA) specifications
The following specifications refer to the transparent materials adapter (TMA) and
not the scanner. The adapter is included with the HP Scanjet 4670 scanner, and
can be purchased separately for the HP Scanjet 4600 scanner.
environmental specifications for the scanner and transparent
materials adapter (TMA)
Name Description
Media types 1 35 mm slide or 1 frame of a 35 mm negative strip
Media capacity Slide: 1.05 to 1.9 mm thick and 49.8 to 50.8 mm on any side
Size 24 x 106.8 x 168 mm (0.95 x 4.2 x 6.6 inches)
Weight 0.23 kg (0.5 pounds)
Power requirements 12.0 VDC, 340 mA, 4.22 watts (supplied by scanner)
Name Description
Temperature Operating: 10° to 35° C (50° to 95° F)
Storage: -40° to 70° C (-40° to 158° F)
Relative humidity Operating: 15 percent to 80 percent noncondensing
10° to 35° C (50° to 95° F)
Storage: up to 90 percent at
0° to 65° C or (32° to 149° F)
