hp workstation c3700 and c3750 technical specifications

processor

hp c3700

hp c3750

type

PA-8700 PA-8700+

clock frequency

750-MHz

875-MHz

number of processors

cache (on-chip)

total cache

2.25-MB

instruction 0.75-MB

data

1.50-MB

main memory

bus bandwidth

1.9-GB/s

RAM type

120-MHz SDRAM

capacity

512-MB to 8-GB

memory slots

8 DIMMs

storage bays

1 floppy, 1 optical, 2 Ultra 2 SCSI LVD

internal storage (2 bays)

up to 2 devices, 146-GB maximum

Ultra 2 SCSI LVD, 80 pin SCA connector

18-GB (10K RPM)

36-GB (10K RPM)

73-GB (10K RPM)

36-GB (15K RPM)

external storage

NSE SCSI (HD50)

1 port - up to 7 devices

Ultra2 SCSI LVD

1 port - up to 13 devices

removable media

floppy drive

1 floppy drive (3.5 inch/1.44-MB)

optical drive

1 DVD or CD-RW

expansion slots (6 total)

PCI 1X (half card)

2 slots

PCI 2X (full size)

3 slots

PCI 4X (full size)

1 slot

integrated networking

LAN data rate

10/100-Mb/s

built-in I/O

serial interface 9-pin DIN

2 ports

parallel interface 25-pin DIN

1 port

USB (Universal Serial Bus) Series A

2 ports (keyboard and mouse only)

audio

type

integrated, CD-quality stereo

inputs

stereo line-in, MIC-in

outputs

stereo line-out, internal speaker,

headphones

environmental specifications

altitude

– operating

0-3000 m (0-10,000 ft)

– non-operating

0-4500 m (0-15,000 ft)

temperature

– operating

5 to +40 degrees C

– non-operating

-40 to +70 degrees C

humidity

– operating

15 to 80% (non condensing)

vibration

– operating random

0.21 G rms, 5-500-Hz

– swept sine survival

0.5 G peak, 5-500-Hz

– random survival

2.09 G rms, 5-500-Hz

safety

UL1950, CUL to CSA C22.2#950,

and TUV GS, Mark to

EN60950/IEC950

emissions

FCC and CISPR Class A

and VCCI Class A

physical dimensions

deskside configuration

height

44.5 cm (17.5 inches)

width

22.9 cm (9.0 inches)

depth

49.5 cm (19.5 inches)

racked configuration

height

6 EIA units

width

48.3 cm (19 inches)

depth

66.5 cm (25.8 inches)

rack orientation

system racks on its side

net weight

minimum configuration

20.9 kg (45.9 lbs.)

fully loaded

25.4 kg (55.8 lbs.)

power requirements

input current

7.4 amps RMS max @ 100-120 V

3.8 amps RMS max @ 220-240 V

line frequency

50-60-Hz

maximum power input

805 watts @120 VAC, 60-Hz

supported operating systems

hp-ux 11i TCOE (Technical Computing Operating Environment)

hp-ux 11i MTOE (Minimal Technical Operating Environment)

hp-ux 11.0
monitors

hp L2025

20 inch LCD, flat-panel

hp L1825

18 inch LCD, flat-panel

hp wide-aspect

24 inch CRT, flat-screen, wide aspect

hp p1130

21 inch CRT, flat-screen

hp p920

19 inch CRT, flat-screen

leadership graphics—entry 3D

hp fxe

4 maximum, 24-MB FB memory,

9.5-MB maximum texture memory at

1280 x 1024 resolution

leadership graphics—mid-range 3D

hp fx

pro

1 maximum, 64-MB FB memory,

48-MB maximum texture memory at

1280 x 1024 resolution

leadership graphics—high-end 3D

hp fx

pro

1 maximum, 128-MB FB memory,

110-MB maximum texture memory at

1280 x 1024 resolution

leadership graphics—extreme 3D

hp Fire GL-UX

1 maximum, 128-MB FB memory,

110-MB maximum texture memory at

1280 x 1024 resolution

For more information about the HP leadership graphics program:

www.hp.com/go/leadershipgraphics

Screen image courtesy of EDS PLM Solutions and Ducati Motor Holding S.p.A., and EDS PLM

Solutions and Industrial Juguetera, S.A. (INJUSA). UNIX is a registered trademark of The Open

Group in the United States and other countries. All other product names mentioned herein may

be trademarks of their respective companies.
