AV2 Video Signal Connection
For easy connection to AV Video Signal, there are a group of AV Video Signal input
ports on the down part on the left side of the machine. The connection method is the
same as AV1.
Y Yellow (VIDEO)
W White (AUDIO-L)
R Red (AUDIO-R)
10
Installation & Connection
Earphone Socket: The TV speakers will be shut off when earphone is inserted
into this socket.
W
W
R
R
Y
Y
S-VIDEO-2
AUDIO-L
AUDIO-R
VIDEO-2
CVBS, DVD Player or other machine
with CVBS/S-Video.
