Page 10
AV1 Video Signal Connection
Through composite cable, connect AV equipment VIDEO output termination to this
machine VIDEO input, and AV equipment AUDIO output termination to this machine
AUDIO input, respectively.
9
Installation & Connection
W
W
R
R
Y
Y
W
W
R
R
Y Yellow (VIDEO)
W White (AUDIO-L)
R Red (AUDIO-R)
CVBS, DVD Player or other machine
with CVBS/S-Video.
