- 6 -
LENS CONNECTOR
Connect Auto Iris Lens
plug
Set Screw
Loosen Locking Ring to adjust mounting
ring
C/CS Mount Adaptor
• C-Mount lens : Turn Counterclockwise
• CS-Mount lens : Turn Clockwise
2. Names & Functions
