• Be sure mower is properly leveled for best mower
per for man ce. See your tractors owner's manual for
ins truc tions
6
3. Push in and turn upper chute until it is in line with lower
chute.
4. Align the bosses on lower chute with alignment slots
on upper chute and slide together.
5. Secure with rubber latch by hooking hole in latch over
latch pin.
UPPER CHUTE (See Figs. 5A and 5B)
1. Lower mower to its lowest cutting position.
2. Assemble upper chute by inserting curved end into
hole in back of cover.
TIP:
Holding upper chute as shown and twisting while
installing in cover will help keep the rubber seal in place.
NOTE
: Handle carefully so as not to damage full bag in di -
ca tor.
5
FIG. 6B
HANDLE
FULL BAG
INDICATOR
LOWER
CHUTE
BOSSES
LATCH PIN
ALIGN-
MENT
SLOT
RUBBER
LATCH
UPPER
CHUTE
COVER
UPPER
CHUTE
COVER
FIG. 6A
