N
KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page TC-1
006-10536-0010 Rev. 10
Oct/2005
TABLE OF CONTENTS
ITEM
PAGE
INTRODUCTION ............................................................... 1-1
DESCRIPTION OF EQUIPMENT ................................................... 1-2
ACRONYMS AND ABBREVIATIONS ................................................. 1-3
TECHNICAL CHARACTERISTICS .................................................. 1-4
A. KRA 405B RADAR ALTIMETER SYSTEM ............................................ 1-4
B. KRA 405B RECEIVER/TRANSMITTER TSO .......................................... 1-4
C. KRA 405B RECEIVER/TRANSMITTER .............................................. 1-4
D. KNI 415/416 INDICATOR ...................................................... 1-7
E. KA 54A ANTENNA ............................................................. 1-8
F. KA 54 ANTENNA (RETROFIT ONLY) .............................................. 1-9
UNITS AND ACCESSORIES SUPPLIED (KRA 405B SYSTEM COMPONENTS) ................ 1-9
A. RADAR ALTIMETER (Receiver/Transmitter) ..................................... 1-9
B. RADAR ALTIMETER INDICATOR - Honeywell KNI 415 or KNI 416 .................. 1-10
C. RADAR ALTIMETER ANTENNAS (2 each) ......................................... 1-10
D. KRA 405B INSTALLATION KIT ................................................. 1-10
E. KNI 415/416 INDICATOR INSTALLATION KIT .................................... 1-11
F. KA 54A RADAR ALTIMETER ANTENNA INSTALLATION KIT ........................... 1-11
ACCESSORIES REQUIRED BUT NOT SUPPLIED ..................................... 1-11
OPTIONAL ACCESSORIES RECOMMENDED BUT NOT SUPPLIED ......................... 1-12
A. CM 2000 CONFIGURATION MODULE KIT P/N 050-03380-0000. ...................... 1-12
B. KPA 900 CONFIGURATION MODULE PROGRAMMER KIT ............................... 1-13
LICENSE REQUIREMENTS ...................................................... 1-14
INSTRUCTIONS FOR CONTINUED AIRWORTHINESS .................................. 1-14
GENERAL INFORMATION ........................................................ 2-1
UNPACKING AND INSPECTING EQUIPMENT ......................................... 2-1
EQUIPMENT INSTALLATION ..................................................... 2-1
