Viewing Product and Fabric Data
83 Embedded Web Server User Guide
Viewing Operating Parameters for a Fabric
To view the Operating Parameters of a product, perform the following procedure:
1. Choose View from the navigation panel.
2. Choose the Operating Parameters tab. The Operating Parameters tab view
displays ( Figure 27 on page 81) showing Switch Parameters and Fabric
Parameters.
This tab view shows the following Switch Parameters information for the
product:
■ BB Credit — the BB_Credit value for the fabric (not available on the
Edge Switch 2/24).
■ R_A_TOV — Resource Allocation Time Out Value (R_A_TOV) used by the
fabric. Specified in tenths of a second.
■ E_D_TOV — Error Detection Time Out Value (E_D_TOV) value used by the
fabric. Specified in tenths of a second.
■ Switch Priority — Priority value of the switch. Values can be Default,
Principal
, and Never Principal.
■ Interop Mode — Interoperability mode of the fabric. Values can be
Homogenous Fabric and Open Fabric 1.0. (This field is not valid if the
product’s Operation Mode is S/390.)
Viewing Fabric Directors and Switches
To view information about the HP high availability fabric directors and switches
on a menu, perform the following procedure:
1. Choose View from the navigation panel.
2. Choose the Fabric tab and the Products tab. The Products tab view displays
( Figure 28 ).
Note: The page may take some time to display. If the message Attempting to
Collect Data
displays in a product cell, you may want to refresh the image to load
data that has been collected. Click the Refresh icon at the top right of the window.
