Page 57
Configuring Zones
57
Embedded Web Server User Guide
illustrates how zones can consist of ports and/or devices installed on
ports in three managed products in a multiswitch fabric.
zoning through a multiswitch fabric
Figure 19: Zoning through a multiswitch fabric
Zone 1
Interswitch Link
Zone 3
Zone 2
Director
Director
Director
