18
On – Always enable the protection mode.
Off – Always disable the protection mode.
Parameter Description
ADHOC_OFDM When the network type is in Ad Hoc mode, that the card can only
work in 11b data rate. It is defined by Wi-Fi organization. If you
want to enable the data rate up to 54Mbps (11g), select
“ADHOC_OFDM”.
Tx Rate There are several options including
Auto/1/2/5.5/11/6/9/12/18/24/36/48/54Mbps for you to select.
When the “Auto” is selected, the device will choose the most
suitable transmission rate automatically. The higher data rate you
designated in the network, the shorter distance is allowed
between the card and the wireless stations.
When the wireless mode is “802.11 B only”, the maximum data
rate is 11Mbps (11b) so that there are only “Auto/1/2/5.5/11Mbps”
options you can select.
Turn Off RF Button If you want to turn off the radio of the card temporarily, click this
button. To turn on the radio, click this button again.
3.6 About
By choosing this option, you can click the hyperlink to connect to the website for the information of the
wireless chipset vendor and review basic information about the Utility such as the Driver, Utility and
EEPROM Version. The MAC Address of the card is displayed in the screen as well.
