14
3.3 Link Status
From the “Link Status” option, you can view all the information of the network you are connecting to.
You can use this tool in while at the same time repositioning the Hi-Gain antenna to find the optimal
location for antenna placement.
Parameter Description
Status Display the SSID and MAC ID of the network the card is
connecting to.
Current Channel Display the number of the radio channel and the frequency used
for the networking.
Parameter Description
Current Tx Rate Display the transmission rate of the network. The maximum
transmission rate is 54Mbps.
Throughput (Kbits/sec) Display the speed of data transmitted and received.
Link Quality This bar indicates the quality of the link. The higher the
percentage, the better the quality.
dBm If you want to know the signal strength in the unit of dBm, select
this check box.
