operating Instructions:
(cont)
Using your Duo ™ Steam Sweeper & floor Sanitizer
To Refill Water Tank:
1) When there is no more water in the tank, the
RED Refill Light will illuminate (Fig 9).
2) To refill the water tank, place the Duo™ on the
Floor Protector Resting Mat, turn it off and unplug
the unit from the electrical wall outlet. Let the unit
cool for 30 seconds. Then remove the cap and pour
in one (1) cupful of water. Do not overfill (Fig 10).
3) once you have refilled the tank with water, follow
the directions for use as described on pgs 8-10 for
hard-surface floors and pgs 12-13 for carpets/rugs.
To Empty the Sweeper Collection Bin:
For optimum performance the Sweeper Colection Bin
should be emptied after each use. To empty the bin:
1) Make sure the Duo™ is turned oFF and unplugged.
2) With the Duo™ facing towards you, grasp the indented
finger grips and pull up on the bin (Fig 11).
3) Carry the bin to a waste container. Press the small
round ‘Push’ button (Fig 12) and tilt the Sweeper
Collection Bin open. Empty into the waste container
(Fig 13).
4) Snap the lid closed and set the Sweeper Collection
Bin securely back into the top of the unit.
To Store the Steam Sweeper & Floor Sanitizer:
1) When you have finished using the Duo™, turn it
oFF, place it on the Floor Protector Resting Mat,
and wait until the unit cools down for approximately
five (5) minutes before removing the Pad Tray and
the Ultra-Microfiber Pad from the base. Remove
them by using your foot to hold the tray by the
tab at the back of the tray while you pull up to
detach it from the steam head. The Duo™ is
specially designed for this ‘No Touch’ method
of removal (Fig 14). Then pull the pad off the tray.
NOTE: The Ultra-Microfiber Pad gets very hot
with the steam. Allow it to cool before pulling it
off the Pad Tray.
2) Unplug the unit, and arrange the cord along the
top and bottom Pivoting Cord Wrap. Store the
unit upright in a protected dry area by standing it
on the Floor Protector Resting Mat or by hanging
it by the Storage Hook.
Fig 10
Fig 11
Fig 9
RED Refill Light
Fig 12
Fig 13
Finger Grips
PUSH
Fig 14
www. HAANUSA.com 877-HAAN DIRECT / 877-422-6347 pg 11
Foot Tab
