7
English
ELECTRONIC CONTROL:
Display Instructions
1. Stand-by status: On initial set-up,
pressing ON/OFF button, the clock
will display “00:00”.
2. Heating Function: Heating indicator
will flash on the display, until
the temperature reaches the set
temperature, then heating indicator
will stop flashing.
3. Heating Level: When setting the
heating temperature, additional bars
will be added as you increase the
heating temperature from 190°F
(Min) to 203°F (Max). The default
temperature is 197°F.
4. Cooling Function: Cooling indicator
will flash on the display, until
the temperature reaches the set
temperature, then cooling indicator
will stop flashing.
5. Cooling Level: When setting the cooling temperature, additional bars will be
added as you increase the cooling (decreasing temperature) from 50°F (Min)
to 43°F (Max). The default cooling temperature is 44.6°F.
6. Anti-Overheat Indicator: When water dispenser is heating, if the hot water tank
is out of water, the water dispenser will stop heating and the Anti-Overheating
indicator and left 2 bars on the Heating Level and right 2 bars Cooling Level
displays will flash. When the Anti-Overheating indicators flash, fill the water
tank and follow Start-Up Instructions.
7. Troubleshooting display: when the screen shows the left and right bars of the
Heating Level display flashing, it shows a heating sensor problem. When the
screen shows the left and right bars of the Cooling Levels display flashing, it
shows a cooling sensor problem. Turn off and unplug the water dispenser then
follow the Start-Up Instructions.
BUTTON INSTRUCTIONS
1. ON/OFF: Press the ON/OFF button and the water dispenser will power ON
and be in Stand-by mode. PLEASE NOTE: You need to press the Hot/+ (#4
below) button to turn on the water heater and the Cold/- (#5 below) button to
turn on the cooling compressor. When in stand-by mode, pressing the ON/
OFF button will cut off all power.
2. Set function: While the dispenser is in stand-by mode, press and hold the
Set button for 2 seconds, the display will go into Set Mode. In Set mode
you will be able to set the clock time, hot water temperature and cold water
temperature.
1
6
4
5
2
3
HOT WATER
ON/OFF SET
HOT/+ NIGHT LIGHT COLD/-
