Heatcraft Refrigeration Products BMG - Manual (Page 4)

Model BMA Air Defrost | 60 Hz
Model
Capacity Fan Data Air Throw
* †
10°F TD
5°F SST
6°C td
- 4°C sst No. CFM m 3 h
Diameter
Extended
(Standard)
Diffused
(Optional)
BTUH Watts in. mm ft. m ft. m
BMA130 13,000 3,810 1 ,300 3,910 18 457 65 20 50 15
BMA155 15,500 4,540 1 ,00 3,740 18 457 65 20 50 15
BMA245 ,500 7,180 2 ,600 7,820 18 457 65 20 50 15
BMA300 30,000 8,790 2 ,00 7,480 18 457 65 20 50 15
BMA365 36,500 10,690 3 6,900 11,730 18 457 65 20 50 15
BMA450 5,000 13,180 3 6,600 11,220 18 457 65 20 50 15
BMA510 51,000 14,940 4 9,00 15,640 18 457 65 20 50 15
BMA600 60,000 17,570 4 8,800 14,960 18 457 65 20 50 15
BMA710 71,000 20,790 5 10,500 17,850 18 457 65 20 50 15
Performance Data
Model BMA Air Defrost | 50 Hz ‡
Model
Capacity Fan Data Air Throw
* †
10°F TD
5°F SST
6°C td
- 4°C sst No. CFM m 3 h
Diameter
Extended
(Standard)
Diffused
(Optional)
BTUH Watts in. mm ft. m ft. m
BMA130 11,960 3,500 1 ,070 3,520 18 457 60 18.5 5 13.5
BMA155 1,60 4,180 1 1,980 3,370 18 457 60 18.5 5 13.5
BMA245 ,50 6,600 2 ,10 7,040 18 457 60 18.5 5 13.5
BMA300 7,600 8,080 2 3,960 6,730 18 457 60 18.5 5 13.5
BMA365 33,580 9,840 3 6,10 10,560 18 457 60 18.5 5 13.5
BMA450 1,00 12,130 3 5,90 10,100 18 457 60 18.5 5 13.5
BMA510 6,90 13,740 4 8,80 14,080 18 457 60 18.5 5 13.5
BMA600 55,00 16,170 4 7,90 13,460 18 457 60 18.5 5 13.5
BMA710 65,30 19,130 5 9,50 16,070 18 457 60 18.5 5 13.5
* Standard molded fan guards allow for extended air throw; optional wire guards promote air diffusion
† Air throw data based on 12-ft. high ceilings with no obstructions where velocity drops to 50 FPM
‡ For EC motors, use 60 Hz capacity and airflow values (Units with EC motors operating at 50 Hz will not see a reduction in performance due to the
electronic control of the motor)
