Page 12
1
Dimensional Data
All Models Dimensions
Model
6 FPI Models
FPI Models
Dimensions
Defrosts
Defrosts
A
B
C
D
E
F
Elec.
Hot
Gas
Elec.
Hot
Gas
in.
mm
in.
mm
in.
mm
in.
mm
in.
mm
in.
mm
BMA130 BME101
-
-
-
39-5/16
1,000
30-1/
770
-
-
-
-
-
-
-15/16
125
BMA155 BME140
-
BML100
-
39-5/16
1,000
30-1/
770
-
-
-
-
-
-
-15/16
125
BMA245 BME190 BMG190 BML165 BMF165 67-5/16
1,710
58-1/
1,480
-
-
-
-
-
-
-15/16
125
BMA300 BME260 BMG260 BML220 BMF220 67-5/16
1,710
58-1/
1,480
-
-
-
-
-
-
-15/16
125
BMA365 BME310 BMG310 BML250 BMF250 95-5/16
2,420
86-1/
2,190
-
-
-
-
-
-
-15/16
125
BMA450 BME390 BMG390 BML330 BMF330 95-5/16
2,420
86-1/
2,190
-
-
-
-
-
-
-15/16
125
BMA510 BME430 BMG430 BML370 BMF370 13-5/16 3,130 11-1/ 2,900
56
1,420 58-1/ 1,480
-
-
-15/16
125
BMA600 BME520 BMG520 BML440 BMF440 13-5/16 3,130 11-1/ 2,900
56
1,420 58-1/ 1,480
-
-
-15/16
125
BMA710 BME620
-
BML530
-
138-13/16 3,530 19-3/ 3,300
51
1,300 53-1/ 1,350 5-1/
650
-15/16
125
NOTE: Evaporator mounting brackets accept up to 1/2" hanger rod
All Models Dimensional Data
22-3/4"
578 mm
15-1/2"
390 mm
23 -1/4"
590 mm
2-1/2"
64 mm
24"
608 mm
18-7/8"
480 mm
17-1/2"
444 mm
Electrical
Connection
End
Refrigerant
Connection
End
Air
Flow
