Heatcraft Refrigeration Products BMG - Manual (Page 13)

13
Motor/Fan/Blade/Guards
Part # Description
5020-S Motor 115V
5020-T Motor 208-230V
4567-T Motor 208-230V Totally Enclosed
25302201 Motor 460V
25304601* Motor 460V Low Temp Totally Enclosed
25308101* Motor 208-230V Low Temp Totally Enclosed
5599-M Run Capacitor (5 MFD) - Used with most PSC Motors
5779-G
Run Capacitor (7.5 MFD) - Used with 25304601
Motor Only
22511601 Run Capacitor (7.5 MFD) - Used with 25399301
25399301 Motor 575V
5064-E Motor Mount
5130-C Fan Blade
4339-X Fan Guard Molded with Logo
5063-E Fan Guard Beige Wire
* Special motors to be used in room ambients -31°F to -50°F
Cabinet Components
Part # Description No. of Fans
40491902 Drain Pan* 1
40492102 Drain Pan* 2
40492302 Drain Pan* 3
40492502 Drain Pan* 4
40492702 Drain Pan* 5
40830101 Header Side Panel 1-5
40830201 Electrical Side Panel 1-5
40830901 Header Connection Panel 1-5
92864003 Drain Fitting 1-5
* Includes provision to mount drain pan heater
Electrical Components
Part # Description
2891040 Room Thermostat
5709-L
Defrost Term. / Fan Delay Thermostat Sealed
Bimetal Type
2890109
Defrost Term. / Fan Delay Thermostat
Adjustable Type
5708-L Heater Limit Thermostat
NOTE: Contact factory for hot gas defrost components not listed
Drain Pan Defrost Heater
(1 per unit)
Part # Description Voltage Color Code
24710301 1 Fan Unit, 530W 208-230V Black
24710302 2 Fan Unit, 950W 208-230V Black
24710303 3 Fan Unit, 1350W 208-230V Black
24710304 4 Fan Unit, 1800W 208-230V Black
24710305 5 Fan Unit, 2000W 208-230V Black
24710401 1 Fan Unit, 530W 460V Red
24710402 2 Fan Unit, 950W 460V Red
24710403 3 Fan Unit, 1350W 460V Red
24710404 4 Fan Unit, 1800W 460V Red
24710405 5 Fan Unit, 2000W 460V Red
24710502 2 Fan Unit, 950W 115V Black, White
24710503 3 Fan Unit, 1350W 115V Black, White
24710504 4 Fan Unit, 1800W 115V Black, White
24710901 1 Fan Unit, 530W 575V Black, Red
24710902 2 Fan Unit, 950W 575V Black, Red
24710903 3 Fan Unit, 1350W 575V Black, Red
24710904 4 Fan Unit, 1800W 575V Black, Red
24710905 5 Fan Unit, 2000W 575V Black, Red
Coil Defrost Heaters
( per unit)
Part # Description Voltage
24710201 1 Fan Unit, 550W 230-460V
24710202 2 Fan Unit, 1100W 230-460V
24710203 3 Fan Unit, 1600W 230-460V
24710204 4 Fan Unit, 2100W 230-460V
24710205 5 Fan Unit, 2400W 230-460V
24711101 1 Fan Unit, 550W 575V
24711102 2 Fan Unit, 1100W 575V
24711103 3 Fan Unit, 1600W 575V
24711104 4 Fan Unit, 2100W 575V
24711105 5 Fan Unit, 2400W 575V
23308001 Heater Clip (1-3 fans) -
23308101 Heater Clip (4-5 fans) -
Right source. Right parts. Right now.
InterLink™ is your link to a complete line of dependable and
certified commercial refrigeration parts, accessories and
innovative electronic controls for all Bohn equipment. At
InterLink, we provide our wholesalers with a comprehensive
selection of product solutions and innovative technologies
for the installed customer base. And every product is built
to ensure the same high performance standards with which
all Heatcraft Refrigeration Products (HRP) brands are built
— backed by a dedicated team to serve every customer
need, delivering at the best lead times in the industry.
Dependable. Versatile. Courteous.
Finally, one simple source for all your replacement needs
from a name you can trust.
For parts, please contact (800) 686-7278 or
visit www.interlinkparts.com.
