HP X510 - Manual (Page 5)

With the HP Data Vault, you can restore files, folders or even an entire hard drive
from centrally-stored backups. The HP Data Vault automatically searches your
network and discovers PCs with Windows Home Server ® connector software
installed, and then backs them up entirely. The HP Data Vault will back up files
for a Mac as well, working in conjunction with Time Machine. We’ve also
incorporated new image recovery features for Macs.
For better efficiency, Microsoft ® Windows Home Server ® backup software supports
de-duplication—it recognizes identical files (across all computers) and will only
save a single copy of redundant files, while keeping track of multiple versions by
date and originating PC.
• open the windows Home Server ® Console. From a
PC, double-click the HP Data Vault desktop shortcut
and select the windows Home Server
® Console icon,
or double-click the windows Home Server ® system tray
icon, and log on. From a mac, click on the HP Data
Vault icon located in the menu Bar and click “launch
Home Server Console.”
• Click the Computers & Backup tab in the top navigation
bar. You will see a list of computers on your office
network that are eligible for backup.
• Click your PC. on the actions Bar, explore the different
actions available, including View Backups, Backup
Now, Configure Backup and remove Backup.
user accounts first use wizard
• while in the windows Home Server ® Console, click
the user accounts tab. when the “user accounts
Setup” window appears, click ok.
• Click add, then complete the add user account
wizard.
• Check the remote access box to enable remote
access (a strong password is required for remote
access).
TrY THIS
Examine backup options
How To
Set up a user account
S T o r E I T
auTomaTIC BaCkuP 5
listing of one computer’s daily backups
HP Data
Vault set up
Setting up the HP Data Vault
is easy. The unit comes with
a power cable, Ethernet
(rJ-45) cable, software and
documentation. The set up
poster included with the HP
Data Vault illustrates the two
simple steps (hardware and
software) to get started.
You will need:
• one or more computers run-
ning microsoft ® windows ®
Vista, windows ® XP,
windows ® mCE or mac ®
oS X 10.5 or later (for any
macs on the network).
Note: up to 10 PC clients
and macs are supported.
• a router with DHCP enabled
to provide an automatic IP
address to the server
• a broadband connection,
such as DSl or cable, for
remote access functionality
• a 100 mbps to 1000 mbps
(gigabit Ethernet) wired
network connection
Hardware set up
Simply plug the power cord
into the HP Data Vault and
the other end into an electrical
outlet. Connect one end of the
Ethernet cable to the HP Data
Vault and the other to an
Ethernet port on your router.
Press the power button on the
back of the HP Data Vault, and
it is ready to go in 60 seconds.
Software installation
The first installation must be
on a windows computer.
Subsequent installations can
be on a windows or mac
computer. Insert the software
installation disk into a network
computer and follow the online
instructions to install the HP
Data Vault. repeat the software
installation on each network
computer running either
windows ® or mac ® oS X 10.5
or later.
5
