1.34
PARTS LIST
ITEM NO.
77 Bush 340154 0 1 1
78 Bearing - Support 410048 0 1 1
79 Cover - Side LH 410032 1 1 1
80 Lever - HOC 480128 1 1 1
81 Spring - HOC 480132 1 1 1
82 Screw - Taptite M6x35 09786 2 2 2
83 Frame - Roller W/A 410011W 1 1 1
84 Shell - Roller 410044 1 1 1
85 Shaft - Roller 411038 1 1 1
86 Key 411037 1 2 2
87 Cover - Drive 411013 1 1 1
88 Chain 411016 0 1 1
89 Sprocket - Roller 411010 0 1 1
90 Screw - Taptite M6x12 09545 4 4 4
91 Bearing - Rear Roller 219102 2 2 2
92 Sprocket - Gearbox 411011 0 1 1
93 Pin 03997 0 1 1
94 Washer Startlock 0201086 1 2 1
95 Spring - Counter Balance 410050 1 1 1
96 Washer - M16 09491 6 4 6
97 Rod - Connecting 410049 1 1 1
98 Washer - Plain 09262 1 1 1
99 Cutter Blade 201026 1 1 1
100 Friction Disc 410057 1 1 1
101 Carrier - Blade 410078 1 1 1
102 Distance Piece 4014 1 1 1
103 Washer - Spring 09273 1 1 1
104 Bolt - Engine 09788 1 1 1
105 Wheel 5218 2 2 2
106 Nut - Nyloc 1/2" UNF 4486 2 2 2
107 Hub - Cap 219143 2 2 2
108 Bush - Axle 410069 2 2 2
109 Axle - Front W/A 410051 1 1 1
110 Fins 410055 1 1 1
111 Cover - Battery 410081 1 1 1
112 Foam Pad Top 412012 0 1 0
113 Charger 412010 0 1 0
114 Handlebar Fitting 411035 1 1 0
115 Bolt - M6 x 40 MU780129 1 1 0
116 Fastner - Panel Edge 410082 1 1 1
QTY.
410D 412D 413D DESCRIPTION PART NO. ITEM NOTE
