PARTS LIST
ITEM NO.
1
Mainframe
410010V
1
1
1
2
Cover- Side RH
410033
1
1
1
3
Screw - Taptite M6x16
09365
28
29
29
4
Rod - Deflector
305103
1
1
1
5
Key - Woodruff
1662
1
1
1
6
Lead - Battery
412014
0
1
0
7
Engine - E/S
412001
0
1
0
Engine -
410007
1
0
1
8
Decal - Engine
-
1
1
1
Contact Briggs
& Stratton
9
Cover - Nut M8
234051
2
2
2
10
Nut - Nyloc M8
09441
2
3
3
11
Knob - HOC
480134
1
1
1
12
Spring - Deflector
410030
1
1
1
13
Guide - Cable
412008
0
2
0
Guide - Cable
410037
0
2
3
14
Handlebar - Lower
410034W
2
2
2
15
Bolt - Saddle
226024
2
2
2
16
Knob - Handlebar
480088
2
2
2
17
Plug - Handlebar
300160
2
2
2
18
Guide - Rope
305093
1
1
1
19
Washer - Plain
09472
4
3
3
20
Nut - Nyloc M6 P Type
09544
3
3
3
21
Module - E/S
412005
0
1
0
22
Key
6426
0
1
0
23
Screw - M6 x 55
09780
1
2
2
24
Nut - Nyloc M6 T Type
09438
3
3
3
25
Control - Throttle
410035
1
1
1
26
Control - Variable Speed
412002
0
1
1
27
Plug - Drive Large
341033
2
2
2
28
Pin - Pivot
340182
2
2
2
29
Screw - Taptite M6 x 12
09546
0
1
1
30
Washer - Nylon
09688
6
2
2
31
Handlebar - Upper
305145W
1
1
1
32
Lever - Clutch
306094W
0
1
1
33
Screw - Plastite
09687
2
2
2
34
Lever - Engine Stop
340179
1
1
1
35
Cable - Clutch
412006
0
1
1
36
Guide - Cable
410037
4
2
2
37
Cable Engine Brake - AD
410036
1
0
0
Inc.114
Cable Engine Brake - AD
412007
0
1
1
QTY.
410D 412D 413D
DESCRIPTION
PART NO.
ITEM NOTE
