1.33
LIST PARTS
ITEM NO.
38 Frame - Grassbag 410038W 1 1 1
39 Fabric - Grassbag 410039 1 1 1
40 Deflector - Rear 410028 1 1 1
41 Bolt - Coach M8x40 09379 2 2 2
42 Plug - Drive Small 300144 4 4 2
43 Ratchet - HOC 410006 1 1 1
44 Decal - HOC 320006 1 1 1
45 Screw - Self Tap Engine 09349 3 3 3
46 Decal - Hayter 410087 1 1 1
47 Chute 410058 1 1 1
48 Nutsert 410076 1 1 1
49 Cover - Underdeck 410060 1 1 1
50 Throwplate 410059 1 1 1
51 Bracket -Cable Mount 412003 0 1 1
52 Spring - Variator 412004 0 1 1
53 Bush - Pivot 411031 0 1 1
54 Underdeck - Assy 410015 1 1 1 Inc. 47,48,50,116
55 Bracket - Variator 411014 0 1 1
56 Washer - 5/16x7/8 09270 0 1 1
57 Screw - Taptite M8x25 09787 0 1 1
58 Pulley - Variator Assy 411001 0 1 1
59 Pulley 411019 0 1 1
60 Pin - Pulley 411023 0 1 1
61 Belt - Gearbox 411025 0 1 1
62 Battery 412009 0 1 0
63 Spring - Clutch 411021 0 1 1
64 Lever - Clutch 411020 0 1 1
65 Box - Battery 410080 1 1 1
66 Foam - Pad Bottom 412013 0 1 0
67 Belt - Crankshaft 411024 0 1 1
68 Bracket - Roller Suport RH 410016 1 1 1
69 Bracket - Gearbox Support 411012 0 1 1
70 Screw - M6x20 Hex Hd. 09575 6 6 6
71 Plate - Securing 219037 1 1 1
72 Bearing - Gearbox 411027 0 2 2
73 Bearing - Support 410047 0 1 1
74 Grip Fix - 5/16" L.D. 04020 1 1 1
75 Gearbox - Assy 411002 0 1 1 Inc. 59,60,63,64
76 Bracket - Roller Suport LH 410002 1 1 1
QTY.
410D 412D 413D
DESCRIPTION PART NO. ITEM NOTE
