HP MSA50 - Manual (Page 8)

HP StorageWorks
Modular Smart Array
50 Enclosure
Shipping Dimensions
(HxWxD)
12 x 23.5 x 33 in (30.24 x 59.22 x 83.16 cm)
Weight (unloaded) 20 lb (9.07 kg)
Weight (loaded) 30 lb (13.61kg)
Redundant Power
Supply, 180 watts
Shipping Dimensions
(HxWxD)
12.75 x 8 x 3.75 in (32.13 x 20.16 x 9.45 cm)
Protocol Support 3Gb/s SAS
1.5Gb/s SATA
O/S Support Defined by specific HP array controller or SAS/SATA adapter used; please refer to the
QuickSpecs and/or User Guide of the specific array controller or adapter
Buttons/LED Indicators
(on front right panel-
listed top to bottom)
UID Button (top)
System Field Replaceable Unit (FRU) LED
EMU Status LED
Fault LED (bottom)
Drive LED Indicators
(on drive trays)
Drive LED (top) - On-line/Activity
Drive Failure LED (bottom) - Drive Fault/Locate
Enclosure Button/ LED
Indicators (back of unit)
UID Button (top)
System FRU (middle)
EMU Status LED (bottom)
Input Requirements Nominal Line Voltage 110 to 240 V AC
Range Line Voltage 90 to 264 V AC
Line Frequency 47 to 63 Hz
Typical Input Current 2.3A at 120 V AC
Relative Humidity (non-
condensing)
Operating 10% to 90%
Shipping 5% to 90%
I/O Module Connector SAS SFF 8470 Connector
Power 180 Watts per supply (load)
Temperature Range Operating 50° to 94° F (10° to 35° C°)
Shipping -40° to 151° F (-40° to 66° C)
NOTE: To maintain proper cooling and airflow, a drive blank or drive must occupy all bays during
operation.
© Copyright 2006 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
QuickSpecs
HP StorageWorks Modular Smart Array 50 Enclosure
Technical Specifications
DA - 12245 Worldwide QuickSpecs — Version 7 — 12-22-2006 Page 8
