18
To Order, Call Toll-Free 1-800-BUEHLER (1-800-283-4537)
Effective 2008
In-Table/Tabletop & Flush Mount Grinder-Polishers
The SuperMet® Grinder is a heavy-duty rotary coarse grinder with rapid material removal rates
designed to planar grind specimen surfaces. The SuperMet
® Grinder comes with a balanced 12 ″
(305mm) bronze wheel powered by an 1800 rpm, 3 Hp (2.2 kW) motor, and a selection of
abrasive discs. It is offered in a 30
″ (762mm) or 36″ (914mm) table height, or without a table,
which can be custom flush mounted.
15-1230-260 SuperMet® Grinder, 30 ″ (762mm) height, 220 VAC, 60 Hz, 3 phase
15-1230-460 SuperMet® Grinder, 30 ″ (762mm) height, 440 VAC, 60 Hz, 3 phase
15-1231-260 SuperMet® Grinder, 36 ″ (914mm) height, 220 VAC, 60 Hz, 3 phase
15-1231-460 SuperMet® Grinder, 36
″ (914mm) height, 440 VAC, 60 Hz, 3 phase
15-1232-260 SuperMet® Grinder, Flush Mount (w/o table), 220 VAC, 60 Hz, 3 phase
15-1232-460 SuperMet® Grinder, Flush Mount (w/o table), 440 VAC, 60 Hz, 3 phase
SuperMet® Coarse Grinder
Accessories
15-5112-060-100 CarbiMet®, 60 Grit, Pack of 100
15-5112-120-100 CarbiMet®, 120 Grit, Pack of 100
15-5112-180-100 CarbiMet®, 180 Grit, Pack of 100
MiniMet® 1000 is designed for low volume laboratories preparing single specimens. This
semi-automatic grinder-polisher prepares a wide variety of materials using the three self
contained preparation bowls and easy-to-use touch panel controls. Its space saving design
employs a patented geometric action that combines the advantages of hand-lapping as well as
mechanical polishing. This motion provides a random polishing action, eliminating any induced
polishing artifacts. Comes complete with 3 polishing bowls, 3 glass discs, a small quantity of
consumables and operating instructions. CE marked.
69-1100 MiniMet® 1000, 80-264 VAC, 50/60 Hz, 1 phase
MiniMet® 1000 Grinder-Polisher
Accessories
69-1111 Caged Specimen Holder, for 1 ″ (25mm) or 14″ (32mm)
Mounted Specimens
69-1112 Caged Specimen Holder, for 12
″ (38mm) Mounts
69-1500 Polishing Bowls, 1 each Black, White, Blue, 4 ″ (100mm)
Diameter
69-1502 Storage Caddie for MiniMet® Bowls, Set of 3
69-1510 Replacement Glass Discs, Set of 3
69-1550 MiniMet® Alignment Fixture, With 3 Drill Bits
69-1552 Set of Three Drill Bits (Replacement)
69-1560 MiniMet® Precision Thinning Attachment
69-1561 Glass Specimen Supports
69-1562 Glass Circular Slides, .496 ″ (13mm) Diameter,
(50 Pieces)
69-1566 MiniMet® 1000 Precision Thinning Attachment
69-1567 Glass Disc, 2.145
″ (55mm) Diameter, (5 Pieces)
69-1570 MiniMet® Electro-mechanical Attachment
69-1575 Electro-mechanical Accessories
69-1580 MiniMet® Thin Section Attachment includes 3 bowls,
glass and section holder
69-1581 Thin Section Bowls, 1 each Black, White, Blue,
4w
″ (121mm) Diameter
69-1582 Thin Section Glass Platens, Replacement,
4
″ (100mm) diameter
69-1583 MiniMet® Thin Section Slide Holder
69-1590 MiniMet® Wafer Polishing Attachment
DuoMet ® 2 Belt Surfacer
Accessories
10-1250* Recirculating System
16-1497 Recirculating System Cart
16-1498 TechMet® Cabinet, 30 ″ (762mm)
16-1499 TechMet® Cabinet, 36
″ (914mm)
16-3100* VacuMet® Dust Removal System
16-3180 Hose and Connector Assembly DuoMet® II
16-5200-080-010 CarbiMet® MetSplice® Abrasive Belts, 4
″ x 36″
(10.2cm x 91.4xm) / wet or dry use, package of 10, 80 (P80) grit
16-5200-120-010 CarbiMet® MetSplice® Abrasive Belts, 4
″ x 36″
(10.2cm x 91.4xm) / wet or dry use, package of 10, 120 (P120) grit
16-5200-180-010 CarbiMet® MetSplice® Abrasive Belts, 4
″ x 36″
(10.2cm x 91.4xm) / wet or dry use, package of 10, 180 (P180) grit
16-5200-240-010 CarbiMet® MetSplice® Abrasive Belts, 4
″ x 36″
(10.2cm x 91.4xm) / wet or dry use, package of 10, 240 (P280) grit
