Page 6
Heat & Glo • Everest • 750-900 Rev. o • 10/08
6
2
3
3
5
4
6
10
9
8
11
17
18
19
Valve Assembly Parts List
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
IPI Valve Assembly
Post Serial #5000
Standing Pilot Valve Assembly
Pre Serial #5000
Service Parts
EVEREST
Beginning Manufacturing Date: Aug. 2000
Ending Manufacturing Date: ______
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM
DESCRIPTION
(SP) Pre 5000
(IPI) Post 5000
1
Manifold Assembly
N/A
750-310A
Y
2
Pilot Assembly NG
485-510A
593-512A
Y
Pilot Assembly LP
485-511A
593-513A
Y
3
Log Orifi ce NG (#53A)
060-801
582-853
Y
Log Orifi ce LP (#64A)
750-800
582-864
Y
4
Orifi ce NG (#45A)
062-801
582-545
Y
Orifi ce LP (#56)
045-802
582-856
Y
5
Grate Assembly
750-360A
750-360A
6
On/Off Rocker Switch
060-521A
060-521A
Y
7
Rocker Switch Assembly
N/A
750-556A
Y
8
Flame Control Knob
571-531
571-531
Y
9
Flex Ball Valve Assembly
302-320A
302-320A
Y
10
Valve NG
060-522
750-500
Y
Valve LP
060-523
750-501
Y
11
Flexible Gas Connector
567-301A
567-301A
Y
12
Battery Pack
N/A
593-594A
Y
14
Junction Box
100-250A
4021-013
Y
13
3 Volt Transformer
N/A
593-593A
Y
15
Module Wire Assembly
N/A
593-590A
Y
16
Module
N/A
593-592
Y
17
Wire Harness
049-552A
N/A
Y
18
Wire Harness
049-551A
N/A
Y
19
Piezo Ignitor
219-513
N/A
Y
