Figure 10. Vertical Baffl e
1. Attach the First Vent Component to the
Starting Collars
To attach the fi rst vent component to the starting collars
of the fi replace:
• Make sure that the fi replace gasket supplied with the
fi replace seals between the fi rst component and the outer
fi replace wrap.
• Refer to Cinch Pipe and Termination Cap installation
instructions.
B. Installing Vent Components
If your vertical vent component is over 10 feet, you may
want to install the included vertical baffl e to improve fl ame
appearance. Vertical baffl e is located in the bag containing
the instruction manual. Center the vertical baffl e on the fi ve
inch vent being used, and with self tapping screws secure
the baffl e to the inside of the fi rebox (see Figure 10).
With vent runs of 30 feet or more without elbows, an
additional baffl e (SRV750-152) is to be used with the
supplied baffl e. This is a service part and is to be purchased
separately.
VERTICAL
BAFFLE 5” EXHAUST
PIPE
2. Assembling Vent Sections
Refer to Cinch Pipe and Termination Cap installation in-
structions.
!
WARNING: ENSURE THAT THE FIBERGLASS
GASKET SUPPLIED WITH THE FIREPLACE
SEALS BETWEEN THE FIRST VENT COMPO-
NENT AND THE OUTER FIREPLACE WRAP.
If the installation is for a termination cap attached directly
to the fi replace, skip to the sections, Install Firestops and
Vent Termination.
