Eiki LC-SD15 - Manual (Page 30)

30
Computer Input
Press the Point 7 8 buttons to
adjust the value.
Press the MENU button to display the On-Screen Menu.
Press the Point
7 8 buttons to move the red frame pointer
to the Image Adjust Menu icon.
1
2 Press the Point d button to move the red frame pointer to
the desired item and then press the SELECT button. The
level of each item is displayed. Adjust each level by pressing
the Point
7 8 buttons.
Move the red frame pointer to
an item and then press the
SELECT button.
Image Adjust Menu
Press the Point 7 button to decrease the contrast and the Point 8
button to increase the contrast. (From 0 to 63.)
Press the Point 7 button to adjust the image darker and the Point
8 button to adjust the image brighter. (From 0 to 63.)
Contrast
Brightness
Press the Point 7 8 buttons to obtain a better balance of contrast.
(From 0 to 15.)
Gamma
Image Adjust Menu icon
Press the Point 7 button to lighten red tone and the Point 8
button to deepen red tone. (From 0 to 63.)
White balance (Red)
Press the Point 7 button to lighten green tone and the Point 8
button to deepen green tone. (From 0 to 63.)
White balance (Green)
Press the Point 7 button to lighten blue tone and the Point 8
button to deepen blue tone. (From 0 to 63.)
White balance (Blue)
Selected Image level
Press the Point 7 8 buttons to select the desired Color temp.
level. (XLow, Low, Mid, or High)
Color temp.
Image Level Adjustment
To reset the adjusted data, select Reset and press the SELECT
button. The confirmation box will appear and then select [Yes]. All
adjustments return to their previous figures.
Reset
Store
Exit the Image Adjust Menu.
Quit
To store the adjusted data, select Store and press the SELECT
button. The confirmation box will appear and then select [Yes].
Stored data can be called up by selecting "Image" in the Image
Level Selection on page 29. If you change the Image level (p29)
without storing the adjusted data, the figures will go back to the
factory default settings.
✔
Note:
• After adjusting the White balance of Red, Green or Blue, the Color temp. level
will change to "Adj.".
The confirmation
box will appear and
then select [Yes].
Image Level Menu
Move the red frame pointer to
a desired image level among
Image 1 to 4 and then press
the SELECT button.
Store icon
Press the SELECT button at
this icon to store the adjusted
data.
