INSTALLATION MANUAL
11
Adjusting Mount
1. To align the projector, simply grab a hold of either side of the mount and gently adjust by lifting
up and pushing down until you have the proper registration. If you wish to add or lessen the
tension, turn the Tension Ring until the desired amount has been achieved. The Tension Ring can
be turned to lock in the registration once the installation is complete.
All other brand and product names are trademarks or registered trademarks of their respected owners.
TENSION RING
Tighten to Lock
Gently Adjust
Loosen to Adjust
