Enterasys Networks 24-Port - Manual (Page 25)

Model BL-69524ENT
Mid-Span Power Hub 24-Port User’s Guide A-3
Electrical Specifications
AC Power Input
DC Port Power Output
Voltage 90–264 V autoranging (46 Hz–63 Hz)
Connector 3-pin with ground
Chassis grounding yes
Power supply single
Power enabling IEEE 802.3af
Power pins Unused pairs, pins 4,5(+), 7,8(-)
Maximum power/port 15.6 W
Maximum power, all ports active 24 ports at 15.6 W each
Module-to-module isolation 1500 V RMS
Overload protection If current reaches 400–450 mA for 300–400
milliseconds, then the port shuts down.
