Safety Information
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Ŷ IMPORTANT
— Save these instructions for local
inspector’s use.
Ŷ IMPORTANT
— Observe all governing codes and
ordinances.
Ŷ Note to Installer – Be sure to leave these
instructions with Consumer.
Ŷ Note to Consumer – Keep these instructions for
future reference.
Ŷ Skill level – Installation of this appliance requires a
qualified installer or electrician.
Ŷ Proper installation is the responsibility of the
installer.
Ŷ
Product failure due to improper installation is not
covered under Warranty.
Ŷ Product is for indoor use only.
ATTENTION INSTALLER: All electric wall ovens
must be hard-wired (direct-wired) into an approved
junction box. A plug and receptacle is NOT permitted
on these products.
FOR YOUR SAFETY:
WARNING
Before beginning the installation,
switch power off at the service panel and lock the
service disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten
a prominent warning device, such as a tag, to the
service panel.
Be sure the oven is securely installed in a cabinet that
is firmly attached to the house structure. Weight on
the oven door could cause the oven to tip and result in
injury. Never allow anyone to climb, sit, stand or hang on
the oven door.
Make sure the wall coverings, counters and cabinets
around the oven can withstand the heat (up to 200°F
[93.3°C]) generated by the oven.
CONTENTS
Safety Information ................................................... 2
Installation Instructions
Step 1, Remove Packaging and Parts ...................... 3
Step 2, Prepare the Opening .................................... 3
Step 3, Door Removal ............................................... 9
Step 4, Electrical Requirements ................................ 9
Step 5, Make Electrical Connections ...................... 10
Step 6, Three-Conductor Branch
Circuit Connection ...................................... 11
Step 7, Four Conductor Branch
Circuit Connection ....................................... 11
Step 8, Slide Oven into Opening ............................ 12
Step 9, Install Mounting Screws ............................. 12
Step 10, Replacing the Oven Door ......................... 13
Step 11, Final Installation Checklist ........................ 13
MODELS AVAILABLE
Pro Models:
ZMB9031 - Stainless Steel
Min Models:
ZMB9032 - Stainless Steel
