wolfappliance.com | 9
36" Gas Cooktop—Contemporary
FLUSH INSTALLATION
FRONT VIEW SIDE VIEW
NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces,
combustible materials cannot be located within this area.
Maximum facade thickness 1"
(25) . 1" (25) thickness extends 17" (432) left and right and 2" (51) above and below centerlines.
Outside corner radius 3 / 8 " (10) .
30"
(762)
13"
(330)
18"
(457)
9"
(229)
E G
36" (914) MIN
RECESS
21"
(533) MIN
RECESS
35" (889)
CUTOUT WIDTH
COUNTERTOP CUTOUT
20"
(508)
2 1 / 2 " (64)
5 / 64 " (2)
COUNTERTOP
PROFILE
5"
(127)
C
L
10"
(254)
1 1 / 4 " (32)
DIAMETER
4" (102)
C
L
3 7 / 8 " (98) MIN –5 1 / 8 " (130) MAX
2" (51) MIN –
5" (127) MAX
Specifications
