7
Flexible Size Cooking Area
Flexible Cooking Areas - All Cooking Zones
A
A. Maximum flex cooking area: 8" (20.3 cm) diameter
The Flexible Size Cooking Area offers the flexibility to cook using
different sizes of cookware. Cookware sizes can range up to a
maximum diameter of 8" (20.3 cm).
Automatic Cooking
All cooking areas have the Automatic Cooking function.
To Start Automatic Cooking:
1. Touch the Power keypad. The indicator light above the
Power keypad will light up.
2. Touch or slide the power slider to the desired power level
and hold for approximately 3 seconds. The area display
will show the selected power level blinking with an “A.”
The cooking area will heat at maximum power for a set
amount of time that is controlled by the electronic control
for the cooking time. After the controlled time is met, the
cooking area power will decrease to the desired power
level and continue cooking.
To Stop Automatic Cooking:
1. Touch or slide the power slider to a desired power level
between “0” and “9.” The area display will show the power
level selected.
At power levels “1” through “9,” the cooking area will
continue to operate at the chosen power level. At power
level “0,” the cooking area will turn off.
Bridge
The Bridge function allows you to use two cooking areas as
one extra-large cooking area. The Bridge function can be
activated when cooking areas are on or when they are off.
To Turn On the Bridge:
1. Touch the Power keypad. The indicator light above the
Power keypad will light up.
2. Turn on either cooking area using the On/Off switch.
3. Touch anywhere on the sliders for both cooking areas at the
same time. “U” and “ ∩ ” symbols will appear.
4. To increase or decrease the power for the Bridge cooking
area, slide the slider of the cooking area showing the power
level to the desired power level. Both cooking areas are
changed together, but they only use one power slider.
To Turn Off the Bridge:
1. Touch anywhere on the sliders for both cooking areas in the
Bridge at the same time. The power level “0” will appear for
both cooking areas.
2. Touch or slide the power slider to Off to turn off the desired
cooking area.
3. Touch the Power keypad to turn off the cooktop when
finished.
The power to the cooktop will automatically turn off 10 seconds
after both of the cooking areas are turned off.
When using the Bridge function, cookware can have a maximum
diameter of 10" (25.4 cm).
NOTE: The Performance Boost function cannot be used on the
cooking areas using the Bridge function.
Pause
The Pause function stops all of the cooking areas in a zone
temporarily and allows restarting each cooking area at the
same setting.
To Use:
1. Touch the Pause keypad. The display light for Pause will
turn on and a Pause symbol “l l” will show in the cooktop
zone being paused. Both cooking areas in the zone will
be paused.
A
A. Maximum single cookware area: 10" (25.4 cm) diameter
