Elektra Beckum PK 300 K User Manual
Page 28
Pos.
Description
Dimension
DIN
Stock-no.
232
Hex. socket head cap screw
M 6x16
912
612 102 3081
233
Feather key
A 6x4x30
6885
672 105 9322
234
Motor 4.2 DNB w/o switch PK 300
101 017 9145
235
Hexagon nut
M 12
934
620 001 7992
236
Bolt
Ø 25x35
139 520 0271
237
Hexagon lock nut
M 12
985
620 202 4139
238
Hexagon lock nut
M 10
985
620 200 2313
239
Carriage bolt
M 6x35
603
611 002 9436
240
Chip case PK 300
101 021 3793
241
Pressure spring
Ø 9.9x2x22.5
705 120 7240
242
Guide bracket PK 300
Fl 16x5x215
148 221 3754
243
Disk spring
23x8.2x0.9
705 307 5104
244
Cover plate, transmission housing
139 220 0084
245
Carriage bolt
M 12x30
603
611 000 0691
246
Saw blade guard w/suction port PK 300
Ø 37.4
138 115 8612
247
Riving knife carrier
60x80x16
238 021 3730
248
Riving knife, std.
Gr. 25x2.5
138 221 3722
249
Gusset plate PK 300
Bl 2.99x80x60
138 221 3749
250
Hexagon nut, Keps type
M 12
620 900 2432
251
Chip case cover w/o hooks PK 300
138 221 3803
252
Hook, chip case cover
Bl 2x20x146
139 220 0386
253
Hexagon head screw
M 6x16
958/933
610 301 5675
254
Suction port
139 120 0501
255
Washer B 6.4
9021
630 500 2087
256
Carriage bolt
M 6x45
603
611 000 0624
257
Wing nut
M 6
700 512 5213
285
Pan head tapping screw
St 3.9x13
7981
617 200 1805
286
Motor brake ass'y
805 504 6132
287
Motor fan 120/13
133 140 8839
288
Fan cover 120/13
133 140 8847
289
Hexagon head bolt
M12x1.5x25 L.H.
961
610 300 1267
290
Brake pad
133 218 5329
294
Terminal box. workstand
133 140 9657
295
Cross rec. pan head screw
M4x12
7985
612 300 2022
296
Rectifier
101 000 1141
297
Lid, terminal box
133 140 9665
298
Pan head screw
5x20
618 901 1421
308
Push stick
10x70x410
139 420 1630
317
Carriage bolt
M6x25
603
611 003 1325
326
Guide rail
149 202 7223
327
Stop block
139 120 0439
328
Cross recessed countersunk head screw
M 6x12
965
613 105 9530
329
Vernier scale, mitre fence
114 120 0450
330
Hexagon socket head cap screw
M 4x20
912
612 110 2640
331
Hexagon nut
M 4
934
620 000 2197
332
Serrated lock washer
A 4.3
6798
630 408 4020
333
Mitre fence body
139 020 0419
334
Ratchet lever
M 6x25
700 600 3847
335
Cross recessed countersunk head screw
St 4.2x13
7982
617 400 1942
336
Mitre fence extrusion end plate, std.
239 109 1725
337
Mitre fence extrusion
300 mm
139 300 5315
338
Mitre fence scale 0-2x45
°
114 120 0441
339
Cross recessed pan head tapping screw
St. 3.5x9.5
7981
617 202 8215
340
Washer
A 4.3
125
630 001 6330
341
Slotted headless screw w/chamfered end
M 6x25
427
616 000 0340
342
Knurled nut
M 6
624 112 5058
343
Extrusion end plate, extented
139 120 0145
350
Rip fence carrier extrusion
S8x48x450
138 321 4420
351
Thumb screw
M6xLB=68
615 019 0299
352
Washer
B6.6 verz.
9021
630 500 2087
353
Square nut
M8 verz.
557
621 800 5126
354
Hex. socket head cap screw
M8x16
912
612 100 0790
355
Rip fence carrier
138 021 4497
356
Set screw
Ø6/M8/Ø20x110
148 521 4379
357
Dish spring
16x8.2x0.6
2093
705 301 6795
358
Clamping fork
138 021 4349
360
Hexagon nut, self-locking
M8
985
620 200 2305
361
Bolt
Ш10/Ш11/Ш17x47
148 521 4360
362
Eccentric clamp
239 020 5484
363
Circlip for shafts
10x1
471
640 004 7349
364
Cross rec. pan head tapping screw
M5x6 galv.
7985
612 314 9287
365
Leaf spring
0.8x25
705 221 4356
366
Thread cutting screw
AM 5x12-St-Lt galv.
7516
617 517 4166
367
Extrusion end plug
57x49x7
138 121 4458
368
Cross rec. counters. head tapping screw
Stz 4.8x19-C-Lt galv.
7982
617 415 5800
369
Slide rail
16x5x200
148 221 4548
370
Holder, magnifying glass
63x36x30
138 121 4393
371
Magnifying glass
Ø 30
138 121 4407
372
Auxiliary fence extrusion
60x35x700
138 321 4447
7000
Mitre-/Crosscut fence
201 020 0108
7002
Spiral hose
Ø 100x1000
785 412 6290
7003
Shoulder plate
139 220 1595
7004
Extension ring
148 521 3674
28
