40 English
Maint
enanc
e
Maintenance
Round Burner head
1. Orient the burner head so that the
opening for the electrode lines up with
the electrode.
2. Install the burner head so that the
electrode passes through the opening for
the electrode. Make sure the burner head
lies flat on the stove top.
Oval burner
1. Orient the burner head so that the
opening for the electrode lines up with
the electrode.
2. Install the burner head so that the
electrode passes through the opening for
the electrode. Make sure the burner head
lies flat on the stove top.
Burner Cap
1. Match the burner caps to the burners by
size, and then reinstall the caps on the
burner heads.
CAUTION
Make sure each cap is reinstalled on the
correct burner head, is centered on the
burner head, and lies flat.
Burner Head
Burner cap
CAUTION
Make sure all burner components (heads
and caps) are reinstalled properly. They
will be stable and rest flat when correctly
installed.
