English 17
C
ookt
op
Gas burners
C
LR
LF RF
RR
Each burner has a corresponding knob
that lets you to set the flame level from LO
to HI. In addition, each burner knob has a
Lite setting. Turning a knob to Lite ignites
the corresponding burner. The burner
indicators are located above each knob
and show which burner the knob controls.
Each burner is designed for specific cooking
purposes. See the table below.
Position Purpose Food type Characteristics
Right Front (RF)
18,000 BTU Power heating Boiling food Maximum output
Right Rear (RR)
5,000 BTU Low simmering Chocolate,
casseroles, sauces Delicate food that
requires low heat
for a long time
Center (C)
10,000 BTU General heating/
Griddling General food/
Pancakes, fried
eggs General-purpose
cooking
Left Front (LF)
17,000 BTU Quick heating General General-purpose
cooking
Left Rear (LR)
9,500 BTU General heating/
Low simmering General food,
casseroles General-purpose
cooking
Ignition
CAUTION
2
1
Make sure all surface burners are properly
installed. To light a burner:
1. Push in the control knob, and then turn
it to the Lite position. You will hear a
“clicking” sound indicating the electronic
ignition system is working properly.
2. After the surface burner lights, turn
the control knob to shift it out of the
Lite position and turn off the electronic
ignition system.
3. Turn the control knob to adjust the flame
level.
