3-4 Operation Rosemount Analytical Inc. A Division of Emerson Process Management
Model 7003M
b. Display Prompts
The Model 7003M prompts the operator
for inputs and also indicates the function
in progress. For example, when entering
the calibration mode, the prompt "CAL" is
displayed for one second after the CAL
key is pressed. Display acronyms are
listed in Table 3-3 through Table 3-9.
CODE DEFINITION
id enter security code prompt
no invalid security code entered - access denied
YES access granted or security code entered is correct
Table 3-3. Security Access Prompts and Responses
CODE DEFINITION
A-1 setpoints for Alarm 1 - ALARM function
A-2 setpoints for Alarm 2 - ALARM function
C-1 setpoints for Alarm 1 - ON/OFF - Controller function
C-2 setpoints for Alarm 2 - ON/OFF - Controller function
On value in which to initiate an Alarm Action (On-setpoint)
OFF value in which to terminate an Alarm Action (Off-setpoint)
dis Alarm is now disabled
Table 3-4. Alarm Settings Prompts and Responses
CODE DEFINITION
CAL initiate a span calibration
PPr enter process pressure value
CPr enter calibration pressure value
GAS Initiate a zero offset calibration (gas)
Table 3-5. Calibration Prompts and Responses
CODE DEFINITION
Set enter system setup mode
4-0 define the current output as 4-20 or 0-20 mA
CLo % concentration that 0/4 mA represents (calibration low)
CHi % concentration that 20 mA represents (calibration high)
Table 3-6. System Setup Prompts and Responses
